Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
326 (428) 9836 3123 01
Name
Description
Fieldbus items
Duration
Tensor ST/SL
String
length
Value
Set signal
/ Reset signal
Time
To next tightening
Tracking
Blue LED
Sound (time duration for all)
Illuminator
TLS ST Tag LED
VIN input
Shows the VIN
number input from
fieldbus, serial or
Ethernet. Changes
as soon as the
number is given.
This is not the VIN
used in the
tightening result.
If the VIN is longer
than the VIN input
length the Power
Focus will take the
first x characters
and cut the end. If
the VIN number is
shorter then this
parameter length
the Power Focus
will not fill with
zero.
24-208 bit
(3-26
bytes)
CSI
One ASCII sign
for each
character.
First byte is
counter. Counter
increases each
time a new
identifier string
inputted.
Identifier selected
/No signal
16-200 bit
(2-25
bytes)
CSC
Identifier input
character string.
One ASCII sign
for each
character.
16-192 bit
(2-24
bytes)
CSCI
In Intel Endian
mode, whole
words.
One ASCII sign
for each
character.
32-208 bit
(4-26
bytes)
CSII
In Intel Endian
mode, whole
words.
One ASCII sign
for each
character.
First byte is
counter. Counter
increases each
time a new
barcode inputted.
U32
Convert barcode
to U32 number.
Corresponding to
Identifier U32 in
To PF side.
