Atlas Copco Power Focus 3000 User Manual

Digital I/O and fieldbus items
9836 3123 01 339 (428)
Description
Fieldbus items
Digital inputs
Name
Description
String
length
Data type
Value
Set signal
/Reset signal
Internal I/O
I/O Expander
ST GPIO
Function button (optional)
Tool stop
Stops the tool.
1 bit
0 = Not used
1 = Stop tool
Stop tool
/no signal
Tool tightening
disable
The function is similar to Tool
Disable, but only for
tightening.
1 bit
0 = Tightening
Enable
1 = Tightening
Disable
Tool tightening
disable
/Tool tightening
enable
X
Tool tightening
pulse
Tool starts tightening if the
pulse is longer than 100 ms and
continues until target or current
limit is reached
1 bit
0 = Not used
1 = Start Tighten
Pulse
Tool tightening
start
/no signal
Unlock tool
Unlocks tool if tool locked by
batch ok or lock on reject
1 bit
0 = Not used
1 = Unlock tool
Unlock tool
/no signal
X
X
X
X
