Atlas Copco Power Focus 3000 User Manual

Parameter list
368 (428) 9836 3123 01
Parameter
number
Parameter name
Description
Default value
T200
Tool start select
source
Defines which device is allowed to start the tool.
When safety trigger is used, GPIO 4 function must be set to ”Off”.
To start the tool, safety trigger and start trigger must be pushed
simultaneously (second button must be pushed within 0.5 s from first
button, order is arbitrary). If any safety trigger or start trigger is released
while tool is running, tool will stop immediately.
Once tool has been started using safety trigger, both buttons must first
be released to allow the tool to be started again.
Options available: Tool trigger, DigIn, Fieldbus, Sync start, Remote
start, Front/Push start, Front/Push start AND Tool trigger, Front/Push
start OR Tool trigger, Safety trigger
Remote start is not available for Tensor STB tools.
Tool trigger
T201
Timer enable tool
Determines if and how the tool shall be locked by default, and requires
to be unlocked by digital input Timer enable tool.
The function unlocks the tool for a period of T202 seconds. Once the
period expires, the tool will be locked again. If a start attempt is made
before T202 seconds have passed, the tool will remain unlocked until it
is stopped or button is released.
Options:
Off: timer enabled tool functionality will not be in use.
Always: timer enabled tool functionality will be in use, and that
tightening, loosening and positioning (for Open end tools) will be
disabled.
Tightening: timer enabled tool functionality will be in use, and that
tightening will be disabled.
Loosening: timer enabled tool functionality will be in use, and that
loosening will be disabled.
Positioning: timer enabled tool functionality will be in use, and that
positioning (for Open end tools) will be disabled.
At least one input source must be configured to use
digital input Timer enable tool, otherwise the
configuration will be useless (the tool will be disabled
and it will not be possible to enable it).
Off
T202
Timer enable tool
time
Timer function within range 0.5 to 5.0 seconds.
For more information, see section 647HTool.
0,5 s
T203
Direction alert
Possibility to add alert to tool direction. Options: Off, CW, CCW.
Off
T204
Alert type
Defines the type of alert for T203. Options: Buzzer, flash tool LEDs,
buzzer and LEDs.
T210
Mode
Defines the function of the Tool accessory bus.
Available options: Off, Power on, General purpose IO, ST Bus
Not applicable on SL drives
Off
T220
Enable
On
T221
Volume
Available options: Low, Medium, High
High
