Event codes
9836 3123 01 389 (428)
This event indicates that the current
running Multistage has not been
performed entirely (the drive has been
shut off or the tool trigger was released
before the end).
Check the additional information to
see which events occurred.
Follow the procedure for those events.
If the second parameter in the sub
information is zero (no event is
indicated), activate P244 Alarm on lost
trigger and P246 Alarm on end time
shutoff in the stage in which the
multistage was aborted.
E126 additional parameter information
 The first integer parameter indicates at which stage that the Multistage was aborted.
 The second integer parameter indicates which event occurred. 0= no event occurred.
 The third and fourth integer parameters, each containing 32 bits, indicate what went wrong with the
tightening.
Example 1: E126 (2, 113, 9, 8)
The multistage was aborted (E126) in stage 2 (first digit), when the tightening reached current limit (E113
Current limit reached rundown aborted). The third digit, 9, equals 1+8 that correspond to Multistage
aborted and Current limit reached. The fourth digit, 8, corresponds to Final angle max exceeded.
NOTE: Current Limit Reached is one of few event codes for which there is a corresponding tightening
error bit.
Example 2: E126 (3, 129, 1, 16896)
The multistage was aborted (E126) in stage 3 (first digit), when torque lower than target occurred (E129
Torque lower than target). The third digit, 1, means Multistage aborted, and the fourth digit 16896 equals
16384+512, Torque less than target and Current monitoring max exceeded.
