Azbil C7G User Manual

4-18
Chapter 4. Functions

G.SOAK clear
In the pattern operation mode, the G.SOAK wait state can be canceled individually
for each control loop.
(1) Press the [] (mode) button on the 1-loop monitor screen.
> The mode selection screen appears.
(2) Press the [PATTERN] button in the upper left corner of the screen.
> The mode selection screen for pattern operation appears.
(3) Press the [CLEAR] button to the right of G.SOAK CLEAR.
> The G.SOAK CLEAR execution confirmation screen appears.
(4) Press the [CLEAR] button.
> The G.SOAK wait period is canceled.
Handling Precautions
• G.SOAK CLEAR can be used only in the G.SOAK wait state.
• In the G.SOAK wait state, the SEG (segment) number display on the monitor
screen blinks.

AT (auto-tuning) stop/start
AT stop/start can be switched for each control loop independently.

AT stop → AT start
(1) Press the [] (mode) button on the 1-loop monitor screen.
> The mode selection screen appears.
(2) Press the [START] button on the right side of AUTO TUNING.
> The confirmation screen for changing the mode to AT start appears.
(3) Press the [START] button.
> The AT starts.

AT start → AT stop
(1) Press the [] (mode) button on the 1-loop monitor screen.
> The mode selection screen appears.
(2) Press the [STOP] button in the right side of AUTO TUNING.
> The confirmation screen for changing the mode to AT stop appears.
(3) Press the [STOP] button to stop AT.
Handling Precautions
• AT can be started by either the master side or the slave side of the internal
cascade control. Master and slave cannot both start AT.
• When AT is active in the pattern operation mode, the progress of pattern
operation is stopped even in the RUN mode. When AT stops or ends, the
controller returns to a state in which it can progress according to the RUN,
HOLD, END, or READY mode.
