Chapter 6. Display and Setting Data

DI/DO CONFIG bank
Bank selection: DI/DO CONFIG
Loop selection: None
Group selection: DI/DO 1 to 7
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
DI/DO1 /
Operation type
DI/DO1 Operation type 0: DI
1: DO
0

-

DI/DO2 /
Operation type
DI/DO2 Operation type Same as DI/DO 1 0

-

DI/DO3 /
Operation type
DI/DO3 Operation type Same as DI/DO 1 0

-

DI/DO4 /
Operation type
DI/DO4 Operation type 0: DI
1: DO
2: TP (time
proportioning)
output
0

-

DI/DO5 /
Operation type
DI/DO5 Operation type Same as DI/DO 4 0

-

DI/DO6 /
Operation type
DI/DO6 Operation type Same as DI/DO 4 0

-

DI/DO7 /
Operation type
DI/DO7 Operation type Same as DI/DO 4 0

-

