Azbil C7G User Manual

6-44
Chapter 6. Display and Setting Data

Virtual analog input bank
Bank selection: VIRTUAL ANALOG INPUT
Loop selection: Virtual AI 1 to 4
Group selection: None

Virtual AI 1
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
Virtual AI assignment Virtual AI
assignment
2048 to 3071: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
2111
# *

2111 is "User-
defined number 1."
Filter Filter 0.0000 to 120.00 0.0000
# *

With decimal point
Ratio Ratio 0.0010 to 10.000 1.0000
# *

With decimal point
Bias Bias −32000 to +32000 0.0000
# *

With decimal point
Linearization table
group
Linearization
table group
definition
0: No linearization
1 to 8
0
# *


Virtual AI 2
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
Virtual AI assignment Virtual AI
assignment
2048 to 3071: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
2112
# *

2112 is "User-
defined number 2."
Filter Filter 0.0000 to 120.00 0.0000
# *

With decimal point
Ratio Ratio 0.0010 to 10.000 1.0000
# *

With decimal point
Bias Bias −32000 to +32000 0.0000
# *

With decimal point
Linearization table
group
Linearization
table group
definition
0: No linearization
1 to 8
0
# *


Virtual AI 3
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Virtual AI assignment Virtual AI
assignment
2048 to 3071: Standard
numerical codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
2113
# *

2113 is "User-
defined number 3."
Filter Filter 0.0000 to 120.00 0.0000
# *

With decimal point
Ratio Ratio 0.0010 to 10.000 1.0000
# *

With decimal point
Bias Bias −32000 to +32000 0.0000
# *

With decimal point
