4-12
Chapter 4. Functions
4 - 3 Mode
Up to four loops can be controlled individually by this device. The following mode selections are available for each
control loop.
• AUTO/MANUAL mode selection
• Constant value operation / Pattern operation selection
• RUN/READY mode selection
• LSP/RSP mode selection
• Pattern start number selection
• READY/RUN/HOLD/END mode selection
• ADVANCE
• G.SOAK clear
• AT (auto tuning) stop/start selection

AUTO/MANUAL mode
The AUTO and MANUAL modes can be switched for each control loop.

AUTO → MANUAL
There are 2 methods of switching.
• Method 1:
(1) Press the [MV] button on the 1-loop monitor screen.
> The confirmation screen for changing the mode to MANUAL appears.
(2) Press the [MANUAL] button.
> The mode is switched to MANUAL.
• Method 2:
(1) Press the [îš„] (mode) button on the 1-loop monitor screen.
> The mode selection screen appears.
(2) Press the [AUTO] button on the right side of AUTO/MANUAL.
> The confirmation screen for changing the mode to MANUAL appears.
(3) Press the [MANUAL] button.
> The mode is switched to MANUAL.

MANUAL → AUTO
There are 2 methods of switching.
• Method 1:
(1) Press the [MANUAL] button on the 1-loop monitor screen.
> The confirmation screen for changing the mode to AUTO appears.
(2) Press the [AUTO] button.
> The mode is switched to AUTO.
