Azbil C7G User Manual

10-13
Chapter 10. PLC Link Communication

Data settings
Transfer sheets 1 to 4 can be set independently. Up to 32 data items can be specified
in total for all sheets combined. The settings for each data item are shown in the
table below.
Setting item Settings Initial value Notes
PLC device type address See the list of address ranges for the
PLC device type.
Not set
C7G data Selectable from the C7G monitor data
and parameters.
Not set
No. of decimal places 0: No decimal point
1: 1 digit after the decimal point
2: 2 digits after the decimal point
3: 3 digits after the decimal point
4: 4 digits after the decimal point
0

Azbil C7G Specifications

General

Brand	Azbil
Model	C7G
Category	Controller
Language	English
