Azbil C7G User Manual

6-17
Chapter 6. Display and Setting Data

EVENT CONFIG bank
Bank selection: EVENT CONFIG
Loop selection: None
Group selection: Event groups 1 to 16

Events 1 to 16 (common)
Item
display
Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Operation
type
Operation
type
0: No event
1: PV high limit
2: PV low limit
3: PV high and low limits
4: Deviation high limit
5: Deviation low limit
6: Deviation high and low limits
7: Deviation high limit (final SP basis)
8: Deviation low limit (final SP basis)
9: Deviation high and low limits (final SP basis)
10: SP high limit
11: SP low limit
12: SP high and low limits
13: MV high limit
14: MV low limit
15: MV high and low limits
16: MFB high and low limits
17 to 25: Reserved
26: Standard numerical code high limit
27: Standard numerical code low limit
28: Standard numerical code high and low limits
29: PV change rate
30 to 54: Reserved
55: PV change rate high limit
56: PV change rate low limit
57: Standard numerical code change rate high limit
58: Standard numerical code change rate low limit
59 to 60: Reserved
61: Alarm (status)
62: READY (status)
63: MANUAL (status)
64: RSP (status)
65: AT running (status)
66: During SP ramp (status)
67: Control direct action (status)
68: Estimating MFB
69: Reserved
70: Timer
0
# *

For
details, refer
to "Operation
(p.4-56),"
"Operation
type and
Loop
definition
(p.4-61)" in
the "Event"
section.
