Azbil C7G User Manual

4-35
Chapter 4. Functions
Item (bank) Display Description Initial value
Loop definition
(DI bank)
MENU > DI
Loop definition
When the operation type is other than
timer stop/start selection,
0: All loops collectively
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
When the operation type is timer stop/
start selection,
0: All timer events
1 to 16: Event number for timer event
0
• Details of the LSP group selection by DI assignment
The values of LSP group selection according to the ON/OFF status of each DI are
shown below.
LSP group selection (0/+1) OFF: 0 ON: 1
LSP group selection (0/+2) OFF: 0 ON: 2
LSP group selection (0/+4) OFF: 0 ON: 4
The LSP group number is determined by adding 1 to the sum of the values of
the LSP group selection by ON/OFF of each DI.
For example, if the sum of the value of LSP group selection is 1, the LSP group
number is 2. However, if the number of LSP system groups is exceeded, the LSP
group number is the same as the number of LSP system groups.
• If the number of LSP system groups is 1, although the value can be displayed and
set, the LSP group selection by DI assignment is invalid.

SP ramp unit
The time unit of the SP ramp can be set to every second, every minute, or every
hour for each control loop.
Item (bank) Display Description Initial value
SP ramp unit
(SP configuration bank)
MENU > SP Config
SP ramp unit
0: s
1: min
2: h
0
