Azbil C7G

4-80
Chapter 4. Functions

Linearization table group definition
The setting is valid if a MOTOR block is inserted (using four slots) into the I/O slot.
The linearization table used for linear approximation of motor drive output can be
set.
The linearization table group selections made by DI (digital input) cannot be
combined.
Item (bank) Display Description Initial value
Linearization table group definition
PP (position proportional) bank
MENU > PP
Linearization table group
0: No linearization
1 to 8
0
Note
• 4 - 16 Linear Approximation (p.4-90) (for details on linearization table
settings)
