6-40
Chapter 6. Display and Setting Data
Handling Precautions
• When Data Selection is “0: Standard,” Number of data and Data1 to Data40 are
disabled.
• When Data Selection is set to "1: Custom" or "2: Ring," data items for the
number set in "Number of data items" are enabled from among Data1 to
Data40.
• If the version of the MAIN block firmware is earlier than 5.x.x (where x is a
wildcard), “Data Selection,” “Number of data,” and “Data1” to “Data40” are not
available. Operation is identical to the case when the data selection is "0:
Standard."
HEALTH INDEX bank
Bank selection: HEALTH INDEX
Loop selection: Loops 1 to 4
Group selection: None
Loops 1 to 4 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Operation type Operation type 0: Stop
1: DI1 status
2: DI2 status
3 to 10: Reserved
11: Event 1
12: Event 2
13: Event 3
14: Event 4
15: Event 5
16: Event 6
17: Event 7
18: Event 8
19: Event 9
20: Event 10
21: Event 11
22: Event 12
23: Event 13
24: Event 14
25: Event 15
26: Event 16
27 to 1023: Reserved
1024 to 2047: Standard bits
14 - 2 Standard Bit
Codes and Standard
Numerical Codes (p.14-6)
0
# *
R value scale R value scale 0 to 10 4
# *
Best data Ideal data 0.0000 to 32000 0.0000
# *
With decimal point
Deviation low
limit
Deviation low
limit
0.0000 to 32000 0.0000
# *
No low limit when 0
With decimal point
Deviation high
limit
Deviation high
limit
0.0000 to 32000 0.0000
# *
No high limit when 0
With decimal point
To Next Page
