Chapter 14. Appendix
14 - 2 Standard Bit Codes and Standard Numerical Codes

Standard bit codes
The range of standard bit codes is 1024 to 2047.
Numbers not listed below are reserved for the system, so do not use them for
configuration.
Standard
bit code
Meaning of standard bit code
1024 Always 0 (OFF)
1025 Always 1 (ON)
1088 Event 1
1089 Event 2
1090 Event 3
1091 Event 4
1092 Event 5
1093 Event 6
1094 Event 7
1095 Event 8
1096 Event 9
1097 Event 10
1098 Event 11
1099 Event 12
1100 Event 13
1101 Event 14
1102 Event 15
1103 Event 16
1120 CT1 heater burnout detection
(block A2)
1121 CT2 heater burnout detection
(blockA2)
1122 CT1 heater burnout detection
(block B2)
1123 CT2 heater burnout detection
(block B2)
1124 CT1 heater burnout detection
(block A1)
1125 CT2 heater burnout detection
(block A1)
1126 CT1 heater burnout detection
(block B1)
1127 CT2 heater burnout detection
(block B1)
1128
CT1 overcurrent detection (block A2)
1129
CT2 overcurrent detection (block A2)
1130
CT1 overcurrent detection (block B2)
1131
CT2 overcurrent detection (block B2)
1132
CT1 overcurrent detection (block A1)
1133
CT2 overcurrent detection (block A1)
1134
CT1 overcurrent detection (block B1)
1135
CT2 overcurrent detection (block B1)
1136
CT1 short-circuit detection (block A2)
1137
CT2 short-circuit detection (block A2)
1138
CT1 short-circuit detection (block B2)
Standard
bit code
Meaning of standard bit code
1139
CT2 short-circuit detection (block B2)
1140
CT1 short-circuit detection (block A1)
1141
CT2 short-circuit detection (block A1)
1142
CT1 short-circuit detection (block B1)
1143
CT2 short-circuit detection (block B1)
1168 DI/DO1 terminal status
1169 DI/DO2 terminal status
1170 DI/DO3 terminal status
1171 DI/DO4 terminal status
1172 DI/DO5 terminal status
1173 DI/DO6 terminal status
1174 DI/DO7 terminal status
1208 DI1 terminal status (block A3)
1209 DI2 terminal status (block A3)
1210 DI3 terminal status (block A3)
1211 DI4 terminal status (block A3)
1212 DI1 terminal status (block B3)
1213 DI2 terminal status (block B3)
1214 DI3 terminal status (block B3)
1215 DI4 terminal status (block B3)
1224 DO1 terminal status (block A1)
1225 DO2 terminal status (block A1)
1226 DO3 terminal status (block A1)
1227 DO4 terminal status (block A1)
1228 DO1 terminal status (block B1)
1229 DO2 terminal status (block B1)
1230 DO3 terminal status (block B1)
1231 DO4 terminal status (block B1)
1280 V-P terminal status (block A2)
1281 V-P terminal status (block B2)
1282 V-P terminal status (block A1)
1283 V-P terminal status (block B1)
1360 Segment event 1
1361 Segment event 2
1362 Segment event 3
1363 Segment event 4
1364 Segment event 5
1365 Segment event 6
1366 Segment event 7
1367 Segment event 8
1368 Segment event 9
1369 Segment event 10
1370 Segment event 11
1371 Segment event 12
Standard
bit code
Meaning of standard bit code
1372 Segment event 13
1373 Segment event 14
1374 Segment event 15
1375 Segment event 16
1408 User-defined bit 1
1409 User-defined bit 2
1410 User-defined bit 3
1411 User-defined bit 4
1412 User-defined bit 5
1413 User-defined bit 6
1414 User-defined bit 7
1415 User-defined bit 8
1416 User-defined bit 9
1417 User-defined bit 10
1418 User-defined bit 11
1419 User-defined bit 12
1420 User-defined bit 13
1421 User-defined bit 14
1422 User-defined bit 15
1423 User-defined bit 16
1440 Result of logical operation 1
1441 Result of logical operation 2
1442 Result of logical operation 3
1443 Result of logical operation 4
1444 Result of logical operation 5
1445 Result of logical operation 6
1446 Result of logical operation 7
1447 Result of logical operation 8
1448 Result of logical operation 9
1449 Result of logical operation 10
1450 Result of logical operation 11
1451 Result of logical operation 12
1452 Result of logical operation 13
1453 Result of logical operation 14
1454 Result of logical operation 15
1455 Result of logical operation 16
1456 Result of logical operation 17
1457 Result of logical operation 18
1458 Result of logical operation 19
1459 Result of logical operation 20
1460 Result of logical operation 21
