6-47
Chapter 6. Display and Setting Data

Pattern bank
Bank selection: PATTERN
Pattern selection: Patterns 1 to 16
Segment selection: None
The table below lists the relevant items for one pattern. These items are the same for
patterns 1 to 16.

Pattern settings
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Number of
segments
Number of segments 1 to 16 16
  
G.SOAK time G.SOAK time 0.0000 to 300.00 s 2.0000
  
With decimal point
PV start PV start 0: Disable PV start
1: Enable PV start
0
  
PV start is only possible
for segment 2.
Cycle Cycle 0 to 32000 times 0
  
Pattern link
Pattern link 0: No link
1 to 16: Link
destination
pattern
number
0
  
End of operation
End of operation 0: READY
1: END
2: Constant value
operation
0
  
Handling Precautions
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), there is no pattern bank.
Note
• When pattern settings are written via communication, RAM and EEPROM (the
normal memory area) are differentiated by the data address. 9 - 5 Pattern
Communication Data (p.9-15)
