Chapter 14. Appendix
Support start date: June 2017
Block Firmware version (X is 0 to 9)
MAIN block 4.0.X
HMI block (display unit, additional display unit) 4.0.X
DI/DO block 3.0.X
RS-485 block 3.0.X
AO-C block (slots A1 to A2, B1 to B2) 3.0.X
V-P block (slots A1 to A2, B1 to B2) 1.0.X
AI block (slots A3 to A4, B3 to B4) 3.0.X
CLOCK block 1.0.X
Added functions
Description User's Manual Reference User's Manual Change
Support for V-P (voltage pulse output)
block
1 - 2 Model No.
Model Selection Guide (p.1-2)
1 and 2 in column A: Added V,
W, N
1 and 2 in column B: Added V, W,
N, G, H, L, P
1 - 4 Input/output Configuration
Input and output configuration diagram
Added voltage pulse output
to the input and output
configuration diagram
4 - 11 TP (Time Proportioning)
Output Function block diagram
Added the diagram “For V-P
block”
4 - 11 TP (Time Proportioning)
Output
TP output type (p.4-69)
TP cycle (p.4-70)
Added items for blocks A2, B2,
A1, B2
6 - 2 Parameter Setting Display
Data
TP (time proportioning) bank (p.6-24)
Added items for blocks A2, B2,
A1, B2
Chapter 13. Specifications
Voltage pulse output (p.13-6)
Added specifications for voltage
pulse output
Added a detection function for heater
burnout/overcurrent/short-circuit via the
CT input of the V-P (voltage pulse output)
block
4 - 14 CT (Current Transformer)
Input
Current measurement and error
detection (p.4-83)
Added the content at left
6 - 1 Operation Display Data
1-loop monitor screen (p.6-2)
Added variable display 5
6 - 2 Parameter Setting Display
Data
CT INPUT bank (p.6-31),
Added the item “For V-P block”
Support for additional display unit
1 - 2 Model No.
Model Selection Guide (p.1-2)
Slots B1 and B2: Added G, H
3 - 4 Wiring
Connecting the cable between the
main unit and display unit (p.3-18)
Added a description of the
additional display unit
6 - 2 Parameter Setting Display
Data
Basic action bank (p.6-9)
Added the “ Additional display
unit” item
