Chapter 6. Display and Setting Data

CONTROL bank
Bank selection: CONTROL
Loop selection: Loops 1 to 4
Group selection: None

Loops 1 to 4 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Control action Control action 0: PID control reverse
(heating)
1: PID control direct
(cooling)
2: PID control heating/
cooling action
3: (Reserved)
4: ON/OFF control
reverse (heating)
5: ON/OFF control
direct (cooling)
0

-

Differential for
ON/OFF control
Differential for ON/OFF
control
0.0000 to 32000 5.0000
# *

Valid when the
control action is in
ON/OFF control.
With decimal point
Heat/Cool control
dead zone
Heating/cooling
control dead zone
-100.00 to +100.00 % 0.0000
# *

Enabled when the
control action is
PID control heating
and cooling action.
With decimal point
PID initial MV PID initial MV -10.000 to +110.00 % 0.0000
# *

When the control
action is changed,
the setting may be
reset to 0.0000 or
50.000.
For details, see
Handling
Precautions
p.6-14.
With decimal point
PID initialization PID initialization 0: Automatic
1: No initialization
2: Initialize (if a new SP
is input)
0
# *

Type of change to
MANUAL
Type of change to
MANUAL
0: Bumpless
1: Preset
0
# *

