13-13
Chapter 13. Specifications
Input type Range type Sensor Range Accuracy Resolution Burnout
Linear 86 Voltage (V) 1 to 5 V ±0.1 % FS ±1 digit 1/90000
min.
Downscale
(−10 % FS)
87 Voltage (V) 0 to 5 V ±0.1 % FS ±1 digit Burnout cannot be detected
(about 0 % FS)
88 Voltage (V) 0 to 10 V ±0.1 % FS ±1 digit Burnout cannot be detected
(about 0 % FS)
89 Current (mA) 0 to 20 mA ±0.1 % FS ±1 digit Burnout cannot be detected
(about 0 % FS)
90 Current (mA) 4 to 20 mA ±0.1 % FS ±1 digit Downscale
(−10 % FS)
92 Voltage (V) −10 to +10 V ±0.1 % FS ±1 digit Burnout cannot be detected
(about 0 % FS)
Input type Range type Sensor Range Accuracy Resolution Burnout
Not used 0 None Fixed to 0
ー ー ー

Input sensor standards
Thermocouple K, E, J, T, B, R, S: JIS C 1602:2015
WRe5-26: ASTM E988-96 (Reapproved 2002)
(JIS C 1602:2015, C thermocouple)
N: JIS C 1602-1995
PLII: ASTM E1751-00
PR40-20: ASTM E1754-00
Resistance temperature detector
Pt100: JIS C 1604-2013
