6-6
Chapter 6. Display and Setting Data
6 - 2 Parameter Setting Display Data
The operations performed by "Write" in the "Communication" column of the table are as follows.
RAM: Data is only written to RAM. Data is not retained in the event of power failure.
EEPROM: Data is written to both RAM and EEPROM. Data is retained in the event of power failure.
Meanings of the symbols in the "Communication" column of the table are as follows.
 Possible with decimal point position settings 0 to 4
* Possible with decimal point position settings 10 to 14
# Possible with decimal point position settings 0 to 4 and 10 to 14
- Not possible
Decimal point position settings 10 to 14 specify RAM access. The value after subtracting 10 is the number of
decimal places.

SP bank
Bank selection: SP
Loop selection: Loops 1 to 4
Group selection: LSP groups 1 to 8, RSP group

Loops 1 to 4 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
LSP1 / SP LSP group 1 SP −32000 to +32000 0.0000 # *

With decimal point
LSP1 / PID group LSP group 1 PID group
number
1 to 8 1 # *

LSP2 / SP LSP group 2 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP2 / PID group LSP group 2 PID group
number
1 # *

LSP3 / SP LSP group 3 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP3 / PID group LSP group 3 PID group
number
1 # *

LSP4 / SP LSP group 4 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP4 / PID group LSP group 4 PID group
number
1 # *

LSP5 / SP LSP group 5 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP5 / PID group LSP group 5 PID group
number
1 # *

LSP6 / SP LSP group 6 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP6 / PID group LSP group 6 PID group
number
1 # *

LSP7 / SP LSP group 7 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP7 / PID group LSP group 7 PID group
number
1 # *

LSP8 / SP LSP group 8 SP Same as LSP group 1 0.0000 # *

With decimal point
LSP8 / PID group LSP group 8 PID group
number
1 # *

RSP / SP RSP group SP Displays the RSP. - - - - Setting is disabled.
RSP / PID group RSP group PID group
number
1 to 8 1 # *

