4-61
Chapter 4. Functions

Operation type and Loop definition
The operation type can be set for an event.
A total of 16 events is available from loops 1 to 4.
Item (bank) Display Description Initial value
Operation type
(Event configuration bank)
MENU > EventConfig
Operation type
0: No event
1: PV high limit
2: PV low limit
3: PV high and low limits
4: Deviation high limit
5: Deviation low limit
6: Deviation high and low limits
7: Deviation high limit (final SP basis)
8: Deviation low limit (final SP basis)
9: Deviation high and low limits (final
SP basis)
10: SP high limit
11: SP low limit
12: SP high and low limits
13: MV high limit
14: MV low limit
15: MV high and low limits
16: MFB high and low limits
17 to 25: Reserved
26: Standard numerical code high limit
27: Standard numerical code low limit
28: Standard numerical code high and
low limits
29: PV change rate
30 to 54: Reserved
55: PV change rate high limit
56: PV change rate low limit
57: Standard numerical code change
rate high limit
58: Standard numerical code change
rate low limit
59 to 60: Reserved
61: Alarm (status)
62: READY (status)
63: MANUAL (status)
64: RSP (status)
65: AT running (status)
66: During SP ramp (status)
67: Control direct action (status)
68: Estimating MFB (status)
69: Reserved
70: Timer
0
Loop definition
(Event configuration bank)
MENU > EventConfig
Loop definition
1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
5 to 2047: Reserved
2048 to 3071: Standard numerical
codes
14 - 2 Standard Bit Codes and
Standard Numerical Codes (p.14-6)
1
