4-71
Chapter 4. Functions

Linearization table group definition
The linearization table group used for TP (time proportioning) output linear
approximation can be set.
Four settings are available for DI/DO groups 4 to 7, and four settings are available
for blocks A2, B2, A1, and B1.
The linearization table group selections made by DI (digital input) can be combined
in the case of blocks A2, B2, A1, and B1.
Item (bank) Display Description Initial value
Linearization table group definition
(TP bank)
MENU > TP
Linearization table group
0: No linearization
1 to 8
0
Handling Precautions
• If a linearization table group is specified for the ON/OFF control output, the
output when linear approximation input = 0 is used when OFF, and the output
when linear approximation input = 100 is used when ON.
Note
• 4 - 16 Linear Approximation (p.4-90) (for details on linearization table
settings)
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands for
any number), linearization table group definition by DI (digital input) cannot be
used.
To Next Page
