6-46
Chapter 6. Display and Setting Data
6 - 3 Pattern Setting Display Data
The operations performed by "Write" in the "Communication" column of the table are as follows.
RAM: Data is only written to RAM. Data is not retained in the event of power failure.
EEPROM: Data is written to both RAM and EEPROM. Data is retained in the event of power failure.
Meanings of the symbols in the "Communication" column of the table are as follows.
: Possible with decimal point position settings 0 to 4
*: Possible with decimal point position settings 10 to 14
#: Possible with decimal point position settings 0 to 4 and 10 to 14
-: Not possible
Decimal point position settings 10 to 14 specify RAM access. The value after subtracting 10 is the number of
decimal places.

Pattern configuration bank
Bank selection: PATTERN CONFIG
Loop selection: Loops 1 to 4
Group selection: None

Loops 1 to 4 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
PTN start number Pattern start number 1 to 16 1
# *

PTN start number
low limit
Pattern start number
low limit
1 to 16 1
# *

PTN start number
high limit
Pattern start number
high limit
1 to 16 16
# *

PTN SP increase
change limit
Pattern SP increase
change limit
0.0000 to 32000
No limit when 0.0000
0.0000
# *

With decimal point
PTN SP decrease
change limit
Pattern SP decrease
change limit
0.0000 to 32000
No limit when 0.0000
0.0000
# *

With decimal point
Handling Precautions
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), there is no pattern configuration bank.
