Azbil C7G User Manual

6-42
Chapter 6. Display and Setting Data

Input assignment bank
Bank selection: INPUT ASSIGNMENT
Loop selection: Loops 1 to 4
Group selection: None

Loop 1
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
PV assignment PV assignment 2048 to 3071: Standard
numerical codes
2312
# *

2312 is "PV (block
A4)."
RSP assignment RSP assignment 2048 to 3071: Standard
numerical codes
2048
# *

2048 is "fixed to
0.0."
Assignment range low
limit
Assignment
range low limit
−32000 to +32000 0.0000
# *

With decimal point
Assignment range high
limit
Assignment
range high limit
−32000 to +32000 1000.0
# *

With decimal point

Loop 2
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
PV assignment PV assignment 2048 to 3071: Standard
numerical codes
2313
# *

2313 is "PV (block
B4)."
RSP assignment RSP assignment 2048 to 3071: Standard
numerical codes
2048
# *

2048 is "fixed to
0.0."
Assignment range low
limit
Assignment
range low limit
−32000 to +32000 0.0000
# *

With decimal point
Assignment range high
limit
Assignment
range high limit
−32000 to +32000 1000.0
# *

With decimal point

Loop 3
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
PV assignment PV assignment 2048 to 3071: Standard
numerical codes
2314
# *

2314 is "PV (block
A3)."
RSP assignment RSP assignment 2048 to 3071: Standard
numerical codes
2048
# *

2048 is "fixed to
0.0."
Assignment range low
limit
Assignment
range low limit
−32000 to +32000 0.0000
# *

With decimal point
Assignment range high
limit
Assignment
range high limit
−32000 to +32000 1000.0
# *

With decimal point
