3-17
Chapter 3. Wiring

Inserting or removing a microSD memory card
Insert the microSD memory card all the way inside. Pushing on the memory card
lightly will enable you to remove the card.
Handling Precautions
• Do not insert or remove a memory card while the indicator next to the
connector is flashing.
• Insertion and removal of a microSD memory card is hazardous as there is a
power input terminal nearby. Be sure to turn off the power before inserting or
removing this card.
• Insert a microSD memory card at a right angle to the main unit.
If the card is tilted, it may not be possible to insert it.
• To transfer the data from a microSD memory card to the personal computer,
use a commercially available adapter or reader/writer.
Incorrect

Connecting the LAN cable for Ethernet
Use a Cat5E or higher LAN cable to make the connection.
LAN cable
To Next Page
