Azbil C7G User Manual

4-34
Chapter 4. Functions

LSP group No.
The LSP group number can be set for each control loop.
(1) Press the [SP] button on the 1-loop monitor screen.
> The SP change screen appears.
(2) Press the Change button on the right side of "LSP/RSP."
> The LSP/RSP selection screen appears.
(3) Press the [LSP] button of the LSP group to be used to select the LSP group.

DI assignment for LSP group selection
LSP group selection can be set for DI groups 1 to 32. If LSP group selection is set
for multiple DI groups, the LSP group is determined by the sum of the values of the
LSP group selected for each DI group.
Item (bank) Display Description Initial value
Operation type
(DI bank)
MENU > DI
Operation type
0: Disabled
1: LSP group selection (0/+1)
2: LSP group selection (0/2)
3: LSP group selection (0/+4)
4: PID group selection (0/+1)
5: PID group selection (0/2)
6: PID group selection (0/4)
7: Reserved
8: PV Hold
9 to 20: Reserved
21: RUN/READY mode selection
22: AUTO/MANUAL mode selection
23: LSP/RSP mode selection
24: AT stop/start selection
25 to 40: Reserved
41: Control operation direct/reverse
selection
42 to 45: Reserved
46: Timer stop/start selection
0
Input type
(DI bank)
MENU > DI
Input type
0: Always OFF
1: Always ON
2 to 10: Undefined
11: DI1
12: DI2
13: DI3
14: DI4
15: DI5
16: DI6
17: DI7
18 to 1023: Reserved
1024 to 2047: Standard bits
14 - 2 Standard Bit Codes and
Standard Numerical Codes (p.14-6)
0
