9-11
Chapter 9. User-defined Addresses
9 - 3 Initial Values of User-Defined Addresses
In this device, the initial settings are set for some user-defined addresses.
Setting item Address Parameter
Decimal point
position
User-defined address 1 100 Monitor: Loop1: PV 1
User-defined address 2 101 Monitor: Loop1: SP 1
User-defined address 3 102 Monitor: Loop1: MV 1
User-defined address 4 103 Monitor: Loop1: RUN/READY 0
User-defined address 5 104 Monitor: Loop1: AUTO/MANUAL 0
User-defined address 6 105 Monitor: Loop1: LSP/RSP 0
User-defined address 7 106 Monitor: Loop1: AT stop/start 0
User-defined address 8 107 SP: Loop1: LSP1 SP 1
User-defined address 9 108 Monitor: Loop1: Manual MV 1
User-defined address 10 109 PID: Loop1: PID1 P (Proportional band) 1
User-defined address 11 110 PID: Loop1: PID1 I (Integral time) 0
User-defined address 12 111 PID: Loop1: PID1 D (Derivative time) 0
User-defined address 13 112 PID: Loop1: PID1 RE (Manual reset) 1
User-defined address 14 113 PID: Loop1: PID1 OL (MV low limit) 1
User-defined address 15 114 PID: Loop1: PID1 OH (MV high limit) 1
User-defined address 16 115 Monitor:
Sum of alarms (Logical sum of all alarms) 0
User-defined address 17 200 Monitor: Loop2: PV 1
User-defined address 18 201 Monitor: Loop2: SP 1
User-defined address 19 202 Monitor: Loop2: MV 1
User-defined address 20 203 Monitor: Loop2: RUN/READY 0
User-defined address 21 204 Monitor: Loop2: AUTO/MANUAL 0
User-defined address 22 205 Monitor: Loop2: LSP/RSP 0
User-defined address 23 206 Monitor: Loop2: AT stop/start 0
User-defined address 24 207 SP: Loop2: LSP1 SP 1
User-defined address 25 208 Monitor: Loop2: Manual MV 1
User-defined address 26 209 PID: Loop2: PID1 P (Proportional band) 1
User-defined address 27 210 PID: Loop2: PID1 I (Integral time) 0
User-defined address 28 211 PID: Loop2: PID1 D (Derivative time) 0
User-defined address 29 212 PID: Loop2: PID1 RE (Manual reset) 1
User-defined address 30 213 PID: Loop2: PID1 OL (MV low limit) 1
User-defined address 31 214 PID: Loop2: PID1 OH (MV high limit) 1
User-defined address 32 300 Monitor: Loop3: PV 1
User-defined address 33 301 Monitor: Loop3: SP 1
User-defined address 34 302 Monitor: Loop3: MV 1
User-defined address 35 303 Monitor: Loop3: RUN/READY 0
User-defined address 36 304 Monitor: Loop3: AUTO/MANUAL 0
User-defined address 37 305 Monitor: Loop3: LSP/RSP 0
User-defined address 38 306 Monitor: Loop3: AT stop/start 0
User-defined address 39 307 SP: Loop3: LSP1 SP 1
User-defined address 40 308 Monitor: Loop3: Manual MV 1
User-defined address 41 309 PID: Loop3: PID1 P (Proportional band) 1
User-defined address 42 310 PID: Loop3: PID1 I (Integral time) 0
User-defined address 43 311 PID: Loop3: PID1 D (Derivative time) 0
User-defined address 44 312 PID: Loop3: PID1 RE (Manual reset) 1
User-defined address 45 313 PID: Loop3: PID1 OL (MV low limit) 1
User-defined address 46 314 PID: Loop3: PID1 OH (MV high limit) 1
User-defined address 47 400 Monitor: Loop4: PV 1
