Azbil C7G

9-12
Chapter 9. User-defined Addresses
Setting item Address Parameter
Decimal point
position
User-defined address 48 401 Monitor: Loop4: SP 1
User-defined address 49 402 Monitor: Loop4: MV 1
User-defined address 50 403 Monitor: Loop4: RUN/READY 0
User-defined address 51 404 Monitor: Loop4: AUTO/MANUAL 0
User-defined address 52 405 Monitor: Loop4: LSP/RSP 0
User-defined address 53 406 Monitor: Loop4: AT stop/start 0
User-defined address 54 407 SP: Loop4: LSP1 SP 1
User-defined address 55 408 Monitor: Loop4: Manual MV 1
User-defined address 56 409 PID: Loop4: PID1 P (Proportional band) 1
User-defined address 57 410 PID: Loop4: PID1 I (Integral time) 0
User-defined address 58 411 PID: Loop4: PID1 D (Derivative time) 0
User-defined address 59 412 PID: Loop4: PID1 RE (Manual reset) 1
User-defined address 60 413 PID: Loop4: PID1 OL (MV low limit) 1
User-defined address 61 414 PID: Loop4: PID1 OH (MV high limit) 1
