Azbil C7G User Manual

6-36
Chapter 6. Display and Setting Data

Graph bank
Bank selection: GRAPH
Loop selection: Loops 1 to 4
Group selection: None
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
LOOP1 / Sampling
cycle
Loop 1
Recording cycle
1 to 3600 s 1
- - -
LOOP1 / Graph
scaling low limit
Loop 1
Graph scaling low
limit
−32000 to +32000 0.0000
- - -
LOOP1 / Graph
scaling high limit
Loop 1
Graph scaling high
limit
−32000 to +32000 100.00
- - -
LOOP2 / Sampling
cycle
Loop 2
Recording cycle
1 to 3600 s 1
- - -
LOOP2 / Graph
scaling low limit
Loop 2
Graph scaling low
limit
−32000 to +32000 0.0000
- - -
LOOP2 / Graph
scaling high limit
Loop 2
Graph scaling high
limit
−32000 to +32000 100.00
- - -
LOOP3 / Sampling
cycle
Loop 3
Recording cycle
1 to 3600 s 1
- - -
LOOP3 / Graph
scaling low limit
Loop 3
Graph scaling low
limit
−32000 to +32000 0.0000
- - -
LOOP3 / Graph
scaling high limit
Loop 3
Graph scaling high
limit
−32000 to +32000 100.00
- - -
LOOP4 / Sampling
cycle
Loop 4
Recording cycle
1 to 3600 s 1
- - -
LOOP4 / Graph
scaling low limit
Loop 4
Graph scaling low
limit
−32000 to +32000 0.0000
- - -
LOOP4 / Graph
scaling high limit
Loop 4
Graph scaling high
limit
−32000 to +32000 100.00
- - -
MULTI / Sampling
cycle
Multi-loop
Recording cycle
1 to 3600 s 1
- - -
For multi-loop
graph screen

ETHERNET bank
Bank selection: ETHERNET
Loop selection: None
Group selection: None
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Modbus/TCP port
number
Modbus/TCP port
number
0 to 65535 502 - - -
