Azbil C7G User Manual

6-31
Chapter 6. Display and Setting Data

CT INPUT bank
Bank selection: CT
Block selection: A2, B2, A1, B1
Group selection: None for the AO-C (current output) block.
"CT1" and "CT2" for the V-P (voltage-pulse output) block

Blocks A2, B2, A1, and B1 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Number of turns Number of turns 100 to 4000 800
# *

For AO-C block
Number of power wire
loops
Number of power wire
loops
1 to 6 1
# *

CT1 / Number of turns Number of CT1 turns 100 to 4000 800
# *

For V-P block
CT1 / Number of power
wire loops
Number of CT1 power
wire loops
1 to 6 1
# *

CT1 / CT operation CT1 CT operation 0: Continuous
current
measurement
1: Heater burnout
detection for OUT
0

-

CT1 / CT measurement
wait time
Waiting time for CT1 CT
measurement
30 to 300 ms 30

-

For V-P block
With decimal
point
CT1 / Burnout
detection value
CT1 heater burnout
detection current value
0.0000 to 350.00 A 0.0000
# *

CT1 / Over-current
detection value
CT1 minimum current
defined as overcurrent
0.0000 to 350.00 A 0.0000
# *

CT1 / Short-circuit
detection value
CT1 minimum current
defined as short-circuit
0.0000 to 350.00 A 0.0000
# *

CT1 / Hysteresis CT1 hysteresis 0.0000 to 350.00 A 0.5000
# *

CT1 / Delay time CT1 delay time 0.0000 to 3200.0 s 2.0000
# *

CT1 / Unmeasured
value condition
CT1 condition for
restoring status before
measurement
1024 to 2047
(Standard bit code)
1024
# *

For V-P block
CT2 / Number of turns Number of CT2 turns 100 to 4000 800
# *

CT2 / Number of power
wire loops
Number of CT2 power
wire loops
1 to 6 1
# *

CT2 / CT operation CT2 CT operation 0: Continuous
current
measurement
1: Heater burnout
detection for OUT
0

-

CT2 / CT measurement
wait time
Waiting time for CT2 CT
measurement
30 to 300 ms 30

-

For V-P block
With decimal
point
CT2 / Burnout
detection value
CT2 heater burnout
detection current value
0.0000 to 350.00 A 0.0000
# *

CT2 / Over-current
detection value
CT2 minimum current
defined as overcurrent
0.0000 to 350.00 A 0.0000
# *

CT2 / Short-circuit
detection value
CT2 minimum current
defined as short-circuit
0.0000 to 350.00 A 0.0000
# *

CT2 / Hysteresis CT2 hysteresis 0.0000 to 350.00 A 0.5000
# *

CT2 / Delay time CT2 delay time 0.0000 to 3200.0 s 2.0000
# *

