Azbil C7G User Manual

6-53
Chapter 6. Display and Setting Data

Alarm condition
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Alarm (logical sum of all alarms that can be displayed) 0: No errors, 1: Error

- -
Block diagnosis alarm 0: No errors
1: Block type error

- -
Memory diagnosis alarm 0: No errors
1: Block with memory failure

- -
Block failure alarm (bit field) Bit field

- -
Bit fields
(p.9-8)
DO overcurrent alarm (bit field) Bit field

- -
SD card alarm 0: No errors, 1: Error

- -
Battery alarm 0: No errors, 1: Error

- -
CT/VT alarm (AO-C block) 0: No errors
1: AO-C block with CT input
error or VT input error

- -
CT alarm (V-P block) 0: No errors
1: V-P block with CT1 input
error or CT2 input error

- -
Loop1 alarm (bit field) Bit field

- -
Bit fields
(p.9-8)
Loop 2 alarm (bit field) Bit field

- -
Loop 3 alarm (bit field) Bit field

- -
Loop 4 alarm (bit field) Bit field

- -
User-defined alarm 1 0: No errors, 1: Error

- -
User-defined alarm 2 0: No errors, 1: Error

- -
User-defined alarm 3 0: No errors, 1: Error

- -
User-defined alarm 4 0: No errors, 1: Error

- -

Monitor/Position proportional
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
OPEN output 0: OFF, 1: ON

- -
CLOSE output 0: OFF, 1: ON

- -
Estimating status 0: Not estimating,
1: Estimating

- -
Adjustment status 0: Not adjusting, 1: Adjusting

- -
Input error 0: No errors, 1: Error

- -
Adjustment error 0: No errors, 1: Error

- -
Opening amount (estimated) −10 to +110 %

- - With decimal point
Opening amount (actual value) −10 to +110 %

- -
MFB count 0 to 32767

- -
