Azbil C7G User Manual

6-54
Chapter 6. Display and Setting Data

Monitor/Pattern mode
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Loop1 Constant value operation/pattern operation 0: Constant value operation
1: Pattern operation
#
*

Loop1 ADVANCE 0: Perform ADVANCE
1: Do not perform ADVANCE
 
-
Loop1 HOLD 0: Do not perform HOLD
1: Perform HOLD
 
-
Loop1 G.SOAK 0: G.SOAK clear
1: G.SOAK wait
 
- Only "0" can be
written.
Note: The items for loops 2 to 4 are the same as those for loop 1.

Monitor/Pattern monitor
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Loop 1 Pattern No. 1 to 16

- -
Loop 1 Segment No. 1 to 16

- -
Loop 1 Pattern SP −32000 to +32000

- - With decimal point
Loop 1 Progress time in segment 0 to 32000

- -
Loop 1 Progress time in pattern 0 to 32000

- -
Loop 1 Number of executing cycle 0 to 32000

- -
Loop 1 Remaining time in segment 0 to 32000

- -
Loop 1 Remaining time in pattern 0 to 32000

- -
Loop 1 Number of remaining cycle 0 to 32000

- -
Loop 1 Setting time in segment 0 to 32000

- -
Loop 1 Setting time in pattern 0 to 32000

- -
Loop 1 Number of setting cycle 0 to 32000

- -
Loop 1 Pattern increase change limit status 0: Not executing
1: Executing

- -
Loop 1 Pattern decrease change limit status 0: Not executing
1: Executing

- -
Note: The items for loops 2 to 4 are the same as those for loop 1.
