6-16
Chapter 6. Display and Setting Data

ANALOG OUTPUT bank
Bank selection: ANALOG OUTPUT
Block selection: A2, B2, A1, B1
Group selection: None

Blocks A2, B2, A1, and B1 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Output range Output range 0: 4–20 mA
1: 0–20 mA
0

-

Output type Output type 0: Fixed at 0 %
1: MV
2: Heat MV
(for heating/cooling
control)
3: Cool MV
(for heating/cooling
control)
4: PV
5: SP
6: Deviation (PV − SP)
7 to 2047: Reserved
2048 to 3071:
Standard numerical
codes
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
1
# *

Loop definition Loop definition 1: Loop 1
2: Loop 2
3: Loop 3
4: Loop 4
1
# *

Output scaling
low limit
Output scaling low
limit
−32000 to +32000 0.0000
# *

With decimal point
Output scaling
high limit
Output scaling high
limit
−32000 to +32000 100.00
# *

With decimal point
Linearization
table group
Linearization table
group definition
0: No linearization
1 to 8
0
# *

