Azbil C7G User Manual

6-8
Chapter 6. Display and Setting Data

ANALOG INPUT bank
Bank selection: ANALOG INPUT
Block selection: A4, B4, A3, B3
Group selection: None

Blocks A4, B4, A3, and B3 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Range type Range type Range of
thermocouple
: 1 to 23
Range of resistance
temperature detector
(RTD) : 41 to 67
Range of DC voltage/
DC current
: 86 to 92
88

-

For details,
refer to Input
types and ranges
(p.13-12).
Linear scaling low
limit
Linear scaling low limit −32000 to +32000 0.0000
# *

Enabled for voltage
input and current
input.
With decimal point
Linear scaling
high limit
Linear scaling high
limit
−32000 to +32000 1000.0
# *

Enabled for voltage
input and current
input.
With decimal point
Filter Filter 0.0000 to 120.00 0.0000
# *

With decimal point
Ratio Ratio 0.0010 to 10.000 1.0000
# *

With decimal point
Bias Bias −32000 to +32000 0.0000
# *

With decimal point
Linearization
table group
Linearization table
group definition
0: No linearization
1 to 8
0
# *

Temperature unit Temperature unit 0:Celsius
1:Fahrenheit
0

-

