6-20
Chapter 6. Display and Setting Data

DO configuration bank
Bank selection: DO CONFIG
Block selection: DI/DO, A1, B1
Group selection: DO 1 to 7 (for DI/DO), DO 1 to 4 (for blocks A1 and B1)

Block DI/DO
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
DO1 / Output type DO1 Output type 0: OFF
1 to 10: Reserved
11: Event 1
12: Event 2
13: Event 3
14: Event 4
15: Event 5
16: Event 6
17: Event 7
18: Event 8
19: Event 9
20: Event 10
21: Event 11
22: Event 12
23: Event 13
24: Event 14
25: Event 15
26: Event 16
27 to 1023: Reserved
1024 to 2047:
Standard bits
14 - 2 Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
0
# *

The output type is
enabled only for
numbers set for
DO in the DI/DO
configuration bank.
DO2 / Output type DO2 Output type Same as DO1 0
# *

Same as DO1
DO3 / Output type DO3 Output type Same as DO1 0
# *

Same as DO1
DO4 / Output type DO4 Output type Same as DO1 0
# *

Same as DO1
DO5 / Output type DO5 Output type Same as DO1 0
# *

Same as DO1
DO6 / Output type DO6 Output type Same as DO1 0
# *

Same as DO1
DO7 / Output type DO7 Output type Same as DO1 0
# *

Same as DO1
