9-2
Chapter 9.
User-defined Addresses
9 - 2
Addr
ess Definition Method
T
o def
ine the data address, u
se the SLP
-C7 Smart Loader Package
. H
ow to define the da
ta address is described below
using the SLP
-C7 screen as an exa
mp
le.

îš„
Setting a user-
defined address
(1)
Open the S
etup scr
een of the SLP
-C7 and clic
k the
[User-Defined Addr
ess]
icon.
(2)
In
pu
t the data addr
ess for co
mm
unication in
to
[Data address]
.
321
323
