Chapter 6. Display and Setting Data

Basic action bank
This holds separate parameters for the standard display unit and additional display
unit. The parameters for one of the display units cannot be set from the other
display unit. However, "Sampling cycle," "Power supply frequency," "Time unit of
patterns," and "Loop1 to 4 Run/Ready at startup" are parameters for the main unit,
not for the display units, which means they can be set from any display unit.
Bank selection: BASIC ACTION
Loop selection: None
Group selection: None

Standard display unit and additional display unit (common)
Item display Item Settings Initial value
Communication
Notes
Read
Write
RAM
EEPROM
Sampling cycle Sampling cycle 0: 10 ms
1: 50 ms
2: 100 ms
1

-

Same setting value
for the standard
display unit and
additional display
unit
Power supply
frequency
Power supply
frequency
0: 50 Hz
1: 60 Hz
0

-

Time unit of
patterns
Time unit of patterns 0: 0.01 s
1: 0.1 s
2: s
3: min
2
# *

HOME screen
layout
HOME screen layout 0: Normal
1: Left/right swap
2: Vertically arranged
0
- - -
Loop1 Run/Ready
at startup
Loop1 Run/Ready at
startup
0: Value stored in
EEPROM
1: RUN
2: READY
0
# *

Same setting value
for the standard
display unit and
additional display
unit
Loop2 Run/Ready
at startup
Loop2 Run/Ready at
startup
0: Value stored in
EEPROM
1: RUN
2: READY
0
# *

Loop3 Run/Ready
at startup
Loop3 Run/Ready at
startup
0: Value stored in
EEPROM
1: RUN
2: READY
0
# *

Loop4 Run/Ready
at startup
Loop4 Run/Ready at
startup
0: Value stored in
EEPROM
1: RUN
2: READY
0
# *

No. of decimal
places for PV1
No. of decimal places
for PV1
0: No decimal point
1: 1 digit after the
decimal point
2: 2 digits after the
decimal point
3: 3 digits after the
decimal point
4: 4 digits after the
decimal point
1
- - -
Applies to the PV
and SP for loop
1 on the monitor
screen.
