6-35
Chapter 6. Display and Setting Data

Linearization table bank
Bank selection: LINEARIZATION TABLE
Loop selection: None
Group selection: Groups 1 to 8

Table groups 1 to 8 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
Operation type Operation type 0: Breakpoint
1: Bias
0
# *

Breakpoint A1 Breakpoint A1 −32000 to +32000 −32000
# *

With decimal point
Breakpoint A2 Breakpoint A2 −32000 to +32000 32000
# *

Breakpoint A3 Breakpoint A3 −32000 to +32000 0.0000
# *

Breakpoint A4 Breakpoint A4 −32000 to +32000 0.0000
# *

Breakpoint A5 Breakpoint A5 −32000 to +32000 0.0000
# *

Breakpoint A6 Breakpoint A6 −32000 to +32000 0.0000
# *

Breakpoint A7 Breakpoint A7 −32000 to +32000 0.0000
# *

Breakpoint A8 Breakpoint A8 −32000 to +32000 0.0000
# *

Breakpoint A9 Breakpoint A9 −32000 to +32000 0.0000
# *

Breakpoint A10 Breakpoint A10 −32000 to +32000 0.0000
# *

Breakpoint B1 Breakpoint B1 −32000 to +32000 −32000
# *

Breakpoint B2 Breakpoint B2 −32000 to +32000 32000
# *

Breakpoint B3 Breakpoint B3 −32000 to +32000 0.0000
# *

Breakpoint B4 Breakpoint B4 −32000 to +32000 0.0000
# *

Breakpoint B5 Breakpoint B5 −32000 to +32000 0.0000
# *

Breakpoint B6 Breakpoint B6 −32000 to +32000 0.0000
# *

Breakpoint B7 Breakpoint B7 −32000 to +32000 0.0000
# *

Breakpoint B8 Breakpoint B8 −32000 to +32000 0.0000
# *

Breakpoint B9 Breakpoint B9 −32000 to +32000 0.0000
# *

Breakpoint B10 Breakpoint B10 −32000 to +32000 0.0000
# *


Cascade bank
Bank selection: CASCADE
Loop selection: None
Group selection: None
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM EEPROM
Scaling method Scaling method 0: Fixed
1: SP basis
2: PV basis
0
# *

Scaling low limit Scaling low limit −32000 to +32000 0.0000
# *

With decimal point
Scaling high limit Scaling high limit −32000 to +32000 100.00
# *

Filter Filter 0.0000: No filter
0.0001 to 120.00s
0.0000
# *

