4-45
Chapter 4. Functions
Handling Precautions
• If cycle operation is set for the source of a link, the pattern link operates after
the cycle operation is completed.
• If the pattern number of the link source is set for the pattern link, the pattern
will be repeated endlessly.
End of operation
The state after the end of pattern operation can be set for each pattern.
If “0: READY” is set, operation will end in READY mode.
If “1: END” is set, operation will end in RUN-END mode.
If “2: Constant value operation” is set, operation will transition to constant value
operation in RUN mode.
Item Display Description Initial value
End of operation
(Pattern bank)
MENU > Pattern
End of operation
0: READY
1: END
2: Constant value operation
0
Handling Precautions
• If one time (1 repetition) or more is set in the cycle count, the device enters the
end of operation state after the cycle(s) are completed.
• If a link destination is set in pattern link, instead of entering the end of
operation state, the device will execute the pattern operation of the link
destination.
• 1 - 6 Operation Modes (p.1-23) (diagram of mode transitions)
• If the device enters the RUN-END mode at the end of operation, the mode
will not be retained if a power failure occurs. When the power is restored, the
device starts operation in the RUN mode from segment 1 of the pattern start
number.
• If the device enters the READY mode or the constant value operation mode at
the end of operation, the mode will be retained even if a power failure occurs.
To Next Page
