Azbil C7G User Manual

12-1
Chapter 12. DISPOSAL
When discarding this unit, dispose of it as industrial waste, following local regulations.

Removing the battery for product disposal
The procedure for removing the battery without using a jig before discarding this
product is described below. Note that this may damage the device or cause faulty
operation.
(1) Pull up the catch at the bottom left of the CLOCK block.
Claw
Clock function block
(2) Place a screwdriver in the groove above the catch at the upper right of the
CLOCK block, and pry the block out of the controller.
Groove above catch
(3) Cut off the pins on the battery with a tool like nippers, and remove the battery
from the board.
Clock function block
Clock
PinPin
Battery
Groove above catch
Catch
