Azbil C7G User Manual

13-12
Chapter 13. Specifications

Input types and ranges
Input type Range type Sensor Range Accuracy Resolution Burnout
Thermocouple 1 K −200 to +1200 °C ±0.1 % FS ±1 digit *
1
0.1 °C Upscale (110 % FS)
2 K 0 to 1200 °C ±0.1 % FS ±1 digit 0.1 °C
3 K 0 to 800 °C ±0.1 % FS ±1 digit 0.1 °C
4 K 0 to 600 °C ±0.1 % FS ±1 digit 0.1 °C
5 K 0 to 400 °C ±0.1 % FS ±1 digit 0.1 °C
6 K −200 to +400 °C ±0.1 % FS ±1 digit *
1
0.1 °C
7 K −200 to +200 °C ±0.1 % FS ±1 digit *
1
0.1 °C
8 J 0 to 1200 °C ±0.1 % FS ±1 digit 0.1 °C
9 J 0 to 800 °C ±0.1 % FS ±1 digit 0.1 °C
10 J 0 to 600 °C ±0.1 % FS ±1 digit 0.1 °C
11 J −200 to +400 °C ±0.1 % FS ±1 digit *
1
0.1 °C
12 E 0 to 800 °C ±0.1 % FS ±1 digit 0.1 °C
13 E 0 to 600 °C ±0.1 % FS ±1 digit 0.1 °C
14 T −200 to +400 °C ±0.1 % FS ±1 digit *
1
0.1 °C
15 R 0 to 1600 °C ±0.1 % FS ±1 digit *
2
0.1 °C
16 S 0 to 1600 °C ±0.1 % FS ±1 digit *
2
0.1 °C
17 B 0 to 1800 °C ±0.2 % FS ±1 digit *
3
0.1 °C
18 N 0 to 1300 °C ±0.1 % FS ±1 digit 0.1 °C
19 PLII 0 to 1300 °C ±0.1 % FS ±1 digit 0.1 °C Upscale (105 % FS)
20 WRe5-26 0 to 1400 °C ±0.1 % FS ±1 digit 0.1 °C Upscale (110 % FS)
21 WRe5-26 0 to 2300 °C ±0.1 % FS ±1 digit 0.1 °C
23 PR40-20 0 to 1900 °C ±0.5 % FS ±1 digit *
4
0.1 °C
*1. For −200 to 0 °C, ±0.2 % FS ±1 digit
*2. For 0 to 100 °C, ±0.2 % FS ±1 digit
*3. For 0 to 260 °C, ±4 % FS ±1 digit. For 260 to 800 °C, ±0.4 % FS ±1 digit
*4. For 0 to 300 °C, ±2.5 % FS ±1 digit. For 300 to 800 °C, ±1.5 % FS ±1 digit
Input type Range type Sensor Range Accuracy Resolution Burnout
RTD 41 Pt100 −200 to +500 °C ±0.1 % FS ±1 digit 0.1 °C Upscale (110 % FS)
43 Pt100 −200 to +200 °C ±0.1 % FS ±1 digit 0.01 °C
45 Pt100 −100 to +300 °C ±0.1 % FS ±1 digit 0.01 °C
47 Pt100 −100 to +200 °C ±0.1 % FS ±1 digit 0.01 °C
49 Pt100 −100 to +150 °C ±0.1 % FS ±1 digit 0.01 °C
51 Pt100 −50 to +200 °C ±0.1 % FS ±1 digit 0.01 °C
53 Pt100 −50 to +100 °C ±0.1 % FS ±1 digit 0.01 °C
55 Pt100 −60 to +40 °C ±0.1 % FS ±1 digit 0.01 °C
57 Pt100 −40 to +60 °C ±0.1 % FS ±1 digit 0.01 °C
59 Pt100 −10 to +60 °C ±0.1 % FS ±1 digit 0.01 °C
61 Pt100 0 to 100 °C ±0.1 % FS ±1 digit 0.01 °C
63 Pt100 0 to 200 °C ±0.1 % FS ±1 digit 0.01 °C
65 Pt100 0 to 300 °C ±0.1 % FS ±1 digit 0.01 °C
67 Pt100 0 to 500 °C ±0.1 % FS ±1 digit 0.1 °C
