Azbil C7G User Manual

6-50
Chapter 6. Display and Setting Data

Monitor/Operation display (Loop1 to 4)
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Loop1: PV Depends on the AI range

- - With decimal
point
Loop1: SP −32000 to +32000
Writing is limited by the common
range of the SP limit low to high
limits and PV range.

- -
Loop1: MV −10 to +110 %

- -
Loop1: Manual MV −10 to +110 %
 
-
Loop1: Heat MV −10 to +110 %

- -
Loop1: Cool MV −10 to +110 %

- -
Loop1: SP group number 1 to 8

- -
Loop1: SP (final value) −32000 to +32000

- - With decimal
point
Loop1: Deviation (PV − SP) −32768 to +32767

- -
Loop1: Deviation (PV − SP) final SP basis −32768 to +32767

- -
Loop1: Current LSP −32000 to +32000

-

Loop1: RSP Depends on the AI range

- -
Loop1: PID group number 1 to 8

- -
Loop1: Current proportional band 0.1 to 3200 %

-

With decimal
point
Loop1: Current integral time 0 to 32000 s

-

Loop1: Current derivative time 0 to 32000 s

-

Loop1: Current manual reset −10 to +110 %

-

Loop1: Current MV low limit −10 to +110 %

-

Loop1: Current MV high limit −10 to +110 %

-

Loop1: Current proportional band for cooling 0.1 to 3200 %

-

Loop1: Current integral time for cooling 0 to 32000 s

-

Loop1: Current derivative time for cooling 0 to 32000 s

-

Loop1: Current MV low limit for cooling −10 to +110 %

-

Loop1: Current MV high limit for cooling −10 to +110 %

-

Loop1: AT progress 0 to 5 (direct or reverse action)
0 to 8 (heating/cooling)

- -
Note: The items for loops 2 to 4 are the same as those for loop 1.

Monitor/Operation display (AO-C block)
Item Settings
Communication
Notes
Read
Write
RAM EEPROM
Block A1 (AO-C): CT current 0 to 350 A
Depends on the setting for
the number of turns and on
the number of passes by the
power wire

- - With decimal
point
Block A1 (AO-C): VT voltage 0 to 264 V
Depends on the primary and
secondary voltage settings

- -
Block A1 (AO-C): CT/VT resistance 0 to 32767 Ω
VT input / CT input

- -
Note:The items for blocks A2, B1, and B2 are the same as those for block A1.
