4-50
Chapter 4. Functions

DI assignment
Items related to DI groups 1 to 32 can be set using DI assignment in the DI settings.
Item (bank) Display Description Initial value
Operation type of DI groups
1 to 32
(DI bank)
MENU > DI
Operation type
0: No function
1: LSP group selection (0/+1)
2: LSP group selection (0/+2)
3: LSP group selection (0/+4)
4: PID group selection (0/+1)
5: PID group selection (0/+2)
6: PID group selection (0/+4)
7: Reserved
8: PV Hold
9 to 10: Reserved
11: Fixed value output selection (0/+1)
12: Fixed value output selection (0/+2)
13: Fixed value output selection (0/+4)
14: Reserved
15: Output linearization table group
selection (0/+1)
16: Output linearization table group
selection (0/+2)
17: Output linearization table group
selection (0/+4)
18 to 20: Reserved
21: RUN/READY mode selection
22: AUTO/MANUAL mode selection
23: LSP/RSP mode selection
24: AT stop/start selection
25 to 40: Reserved
41: Control operation direct/reverse
selection
42 to 45: Reserved
46: Timer stop/start selection
47 to 50: Reserved
51: RUN/READY mode selection (edge)
52: AUTO/MANUAL mode selection (edge)
53: LSP/RSP mode selection (edge)
54 to 59: Reserved
60: Constant value operation / Pattern
operation mode selection
61: ADVANCE (edge)
62: HOLD
63: G.SOAK clear
64 and 65: Reserved
66:
Constant value operation / Pattern operation
mode selection (edge)
67: HOLD (edge)
68 and 69: Reserved
70: Pattern selection (0/+1)
71: Pattern selection (0/+2)
72: Pattern selection (0/+4)
73: Pattern selection (0/+8)
74: Pattern selection (0/+16)
0
