Chapter 4. Functions

Fixed value output
Fixed value output selected by DI (digital input) can be output instead of the MV
from PID control. There are eight fixed value output settings for each loop, and
they can be selected by the sum of the weights of the digital inputs. However, when
the sum of the weights is "0," fixed value output cannot be used. If the sum of the
weights exceeds 8, fixed value output 8 is selected.
Fixed value output has a higher priority than the MV of the PID control, Output at
PV alarm, or Output at READY, but it is lower than the MV in MANUAL mode.
Fixed value output can be set for each control loop.
Item (bank) Display Description Initial value
Fixed value output 1
(CONTROL bank)
MENU > Control
Fixed value output 1
-10.000 to +110.00% 0.0000
Fixed value output 2
(CONTROL bank)
MENU > Control
Fixed value output 2
Fixed value output 3
(CONTROL bank)
MENU > Control
Fixed value output 3
Fixed value output 4
(CONTROL bank)
MENU > Control
Fixed value output 4
Fixed value output 5
(CONTROL bank)
MENU > Control
Fixed value output 5
Fixed value output 6
(CONTROL bank)
MENU > Control
Fixed value output 6
Fixed value output 7
(CONTROL bank)
MENU > Control
Fixed value output 7
Fixed value output 8
(CONTROL bank)
MENU > Control
Fixed value output 8
Note
• 4 - 8 DI (Digital Input) (p.4-49) (for information on selection or weighting
by DI for fixed value output)
Handling Precautions
• If the version of the MAIN block firmware is earlier than 6.x.x (where x stands
for any number), the fixed value output function is not available.
