6-24
Chapter 6. Display and Setting Data

TP (time proportioning) bank
Bank selection: TP (TIME PROPORTIONAL)
Block selection: DI/DO, A2, B2, A1, B1
(when A2, B2, A1, B1 are V-P blocks)
Group selection: DO groups 4 to 7 (for DI/DO block)
None (for the A2, B2, A1, B1 blocks)

Block DI/DO / DO groups 4 to 7 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
TP output type TP output type 0: OFF
1: MV of loop 1
2: MV of loop 2
3: MV of loop 3
4: MV of loop 4
5 to 10:Reserved
11: Heat MV of loop 1
(for heating/
cooling control)
12: Cool MV of loop 1
(for heating/
cooling control)
13: Heat MV of loop 2
(for heating/
cooling control)
14: Cool MV of loop 2
(for heating/
cooling control)
15: Heat MV of loop 3
(for heating/
cooling control)
16: Cool MV of loop 3
(for heating/
cooling control)
17: Heat MV of loop 4
(for heating/
cooling control)
18: Cool MV of loop 4
(for heating/
cooling control)
19 to 2047: Reserved
2048 to 3071:
Standard numerical
codes
14 - 2 Standard
Bit Codes and
Standard Numerical
Codes (p.14-6)
0
# *

The output type is
also set for ON/OFF
control.
TP cycle TP cycle 0.1000 to 120.00 s 10.000

-

