Azbil C7G User Manual

6-25
Chapter 6. Display and Setting Data
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
TP operation type TP operation type 0: Priority on
controllability
1: Priority on device
life (only one ON/
OFF operation
within the time
proportional cycle)
0

-

Linearization
table group
Linearization table
group definition
0: No linearization
1 to 8
0
# *


Blocks A2, B2, A1, and B1 (common)
Item display Item Settings
Initial
value
Communication
Notes
Read
Write
RAM
EEPROM
TP output type TP output type 0: OFF
1: MV of loop 1
2: MV of loop 2
3: MV of loop 3
4: MV of loop 4
5 to 10:Reserved
11: Heat MV of loop
1 (for heating/
cooling control)
12: Heat MV of loop
1 (for heating/
cooling control)
13: Heat MV of loop
2 (for heating/
cooling control)
14: Heat MV of loop
2 (for heating/
cooling control)
15: Heat MV of loop
3 (for heating/
cooling control)
16: Heat MV of loop
3 (for heating/
cooling control)
17: Heat MV of loop
4 (for heating/
cooling control)
18: Heat MV of loop
4 (for heating/
cooling control)
19 to 2047: Reserved
2048 to 3071:
Standard numerical
codes
Standard Bit
Codes and Standard
Numerical Codes
(p.14-6)
0
# *

The output type is
also set for ON/OFF
control.
TP cycle TP output cycle 0.1000 to 120.00 s 2.0000

-

