4-13
Chapter 4. Functions
• Method 2:
(1) Press the [] (mode) button on the 1-loop monitor screen.
> The mode selection screen appears.
(2) Press the [MANUAL] button on the right side of AUTO/MANUAL.
> The confirmation screen for changing the mode to AUTO appears.
(3) Press the [AUTO] button.
> The mode is switched to AUTO.
Handling Precautions
• The master side of the internal cascade control is fixed in AUTO mode.

Constant value operation / Pattern operation
Each control loop can be switched independently between constant value operation
and pattern operation.

Constant value operation → Pattern operation
(1) Press the [SP] button on the 1-loop monitor screen.
> The SP change screen appears.
(2) Press the Change button to the right of "PATTERN OPERATION."
> The constant value operation / pattern operation selection screen appears.
(3) Press the [PTN] button (displaying "PTN," the pattern number, and the SP).
> The confirmation screen for changing the mode to pattern operation appears.
(4) Press the [PATTERN] button.
> The mode changes to the pattern operation mode.

Pattern operation → Constant value operation
(1) Press the [SP] button on the 1-loop monitor screen.
> The SP change screen appears.
(2) Press the Change button to the right of "PATTERN OPERATION."
> The constant value operation / pattern operation selection screen appears.
(3) Press the [LSP] button or [RSP] button (displaying "LSP" with an LSP number
or "RSP," and the SP).
> The confirmation screen for changing the mode to constant value operation
(LSP/RSP) appears.
(4) Press the [LSP/RSP] button.
> The mode changes to the constant value operation mode.
Handling Precautions
• If “Number of patterns” is set to “0: Do not use pattern operation,” ”PATTERN
OPERATION” is not displayed on the SP change screen. In this case, change the
setting of “Number of patterns” by the SLP-C7 Smart Loader Package.
• For control loops on either the master or the slave side of the internal cascade,
only the constant value operation mode is available, so the mode cannot be
switched to pattern operation.
