Azbil C7G User Manual

14-8
Chapter 14. Appendix

Standard numerical codes
Standard
numerical code
Meaning of standard numerical code
2048 Fixed at 0.0
2111 User-defined value 1
2112 User-defined value 2
2113 User-defined value 3
2114 User-defined value 4
2115 User-defined value 5
2116 User-defined value 6
2117 User-defined value 7
2118 User-defined value 8
2119 User-defined value 9
2120 User-defined value 10
2121 User-defined value 11
2122 User-defined value 12
2123 User-defined value 13
2124 User-defined value 14
2125 User-defined value 15
2126 User-defined value 16
2288 Virtual AI 1
2289 Virtual AI 2
2290 Virtual AI 3
2291 Virtual AI 4
2296 Virtual PV 1
2297 Virtual PV 2
2298 Virtual PV 3
2299 Virtual PV 4
2304 AI (block A4)
2305 AI (block B4)
2306 AI (block A3)
2307 AI (block B3)
2312 PV (block A4)
2313 PV (block B4)
2314 PV (block A3)
2315 PV (block B3)
2320 Loop 1 PV
2321 Loop 2 PV
2322 Loop 3 PV
2323 Loop 4 PV
2336 Loop 1 SP (in use)
2337 Loop 2 SP (in use)
2338 Loop 3 SP (in use)
2339 Loop 4 SP (in use)
2352 Loop 1 SP (final value)
2353 Loop 2 SP (final value)
2354 Loop 3 SP (final value)
2355 Loop 4 SP (final value)
2416 Loop 1 MV
2417 Loop 2 MV
Standard
numerical code
Meaning of standard numerical code
2418 Loop 3 MV
2419 Loop 4 MV
2432 Loop 1 Heat MV
2433 Loop 2 Heat MV
2434 Loop 3 Heat MV
2435 Loop 4 Heat MV
2448 Loop 1 Cool MV
2449 Loop 2 Cool MV
2450 Loop 3 Cool MV
2451 Loop 4 Cool MV
2464 MFB opening amount (estimated)
2472 MFB opening amount (actual value)
2479 MFB count value
2496 CT1 measured current when output ON
(block A2)
2497 CT2 measured current when output ON
(block A2)
2498 CT1 measured current when output ON
(block B2)
2499 CT2 measured current when output ON
(block B2)
2500 CT1 measured current when output ON
(block A1)
2501 CT2 measured current when output ON
(block A1)
2502 CT1 measured current when output ON
(block B1)
2503 CT2 measured current when output ON
(block B1)
2512 CT1 measured current when output OFF
(block A2)
2513 CT2 measured current when output OFF
(block A2)
2514 CT1 measured current when output OFF
(block B2)
2515 CT2 measured current when output OFF
(block B2)
2516 CT1 measured current when output OFF
(block A1)
2517 CT2 measured current when output OFF
(block A1)
2518 CT1 measured current when output OFF
(block B1)
2519 CT2 measured current when output OFF
(block B1)
2528 Loop 1 deviation (PV − SP)
2529 Loop 2 deviation (PV − SP)
2530 Loop 3 deviation (PV − SP)
2531 Loop 4 deviation (PV − SP)
2544 CT input value (block A2)
