14-9
Chapter 14. Appendix
Standard
numerical code
Meaning of standard numerical code
2545 CT input value (block B2)
2546 CT input value (block A1)
2547 CT input value (block B1)
2548 VT input value (block A2)
2549 VT input value (block B2)
2550 VT input value (block A1)
2551 VT input value (block B1)
2552 Resistance (block A2)
2553 Resistance (block B2)
2554 Resistance (block A1)
2555 Resistance (block B1)
2656 Event 1 timer remaining time
2657 Event 2 timer remaining time
2658 Event 3 timer remaining time
2659 Event 4 timer remaining time
2660 Event 5 timer remaining time
2661 Event 6 timer remaining time
2662 Event 7 timer remaining time
2663 Event 8 timer remaining time
2664 Event 9 timer remaining time
2665 Event 10 timer remaining time
2666 Event 11 timer remaining time
2667 Event 12 timer remaining time
2668 Event 13 timer remaining time
2669 Event 14 timer remaining time
2670 Event 15 timer remaining time
2671 Event 16 timer remaining time
2736 CT1 Time proportioning current (block
A2)
2737 CT2 Time proportioning current (block
A2)
2738 CT1 Time proportioning current (block
B2)
2739 CT2 Time proportioning current (block
B2)
2740 CT1 Time proportioning current (block
A1)
2741 CT2 Time proportioning current (block
A1)
2742 CT1 Time proportioning current (block
B1)
2743 CT2 Time proportioning current (block
B1)
2752 Loop 1 specific R value
2753 Loop 2 specific R value
2754 Loop 3 specific R value
2755 Loop 4 specific R value
2760 Loop 1 R value
2761 Loop 2 R value
2762 Loop 3 R value
Standard
numerical code
Meaning of standard numerical code
2763 Loop 4 R value
2768 AO-C percent output value (block A2)
2769 AO-C percent output value (block B2)
2770 AO-C percent output value (block A1)
2771 AO-C percent output value (block B1)
2776 V-P percent output value (block A2)
2777 V-P percent output value (block B2)
2778 V-P percent output value (block A1)
2779 V-P percent output value (block B1)
2787 TP percent output value (DO4)
2788 TP percent output value (DO5)
2789 TP percent output value (DO6)
2790 TP percent output value (DO7)
