1-2
Chapter 1. Overview
1 - 2 Model No.

Model Selection Guide

Block name
Symbol Block Name Description
AI Analog input Full multi-range input (thermocouple, RTD, DC current, DC voltage)
V-P Voltage pulse
output
Voltage pulse output (12 V DC)
2 input terminals for the current transformer (CT) for detecting heater burnout,
overcurrent, and short circuits*
1
AO-C Analog current
output
Current output (4–20 mA DC / 0–20 mA DC)
Input terminals for the current transformer (CT) for measuring current and the voltage
transformer (VT) for measuring voltage (1 each)*
1
HMI2 Additional
display unit
Connector for the second display unit*
2
CLOCK Clock function Clock (available for CDS and health index) with a battery
MOTOR Motor drive
output
Motor drive outputs (100/200 V AC) (direct (OPEN), reverse (CLOSE))
with motor feedback (MFB) inputs
DI Digital input 4 digital inputs (external power source required)
DO Digital output 4 digital outputs (sink output)
*1. Current transformer (CT) and voltage transformer (VT) are sold separately.
*2. Additional display unit is sold separately.

Accessories
Part name
Qty.
Notes
Standard (separate)
mounting model
(C7G_4)
Integrated mounting
model
(C7G_3)
Main unit 1 1
Display unit 1 1
Standard gasket 1 0 Mounted on the display unit
Gasket with 92 × 92 mm hole 0 1
Display unit mounting screws
(6 mm)
5 5 4 screws plus 1 spare
Display unit mounting screw
(10 mm)
5 0 4 screws plus 1 spare
Setscrew for temporary
mounting
2 0
Integrating bracket 0 1
Integrating cable 0 1
Installation Manual 1 1 Document No. CP-UM-5487JE
To Next Page
