Azbil C7G User Manual

1-3
Chapter 1. Overview

Model C7G (UL-compliant) Example: C7GA411CC0DA0
Main unit I/O Other
DescriptionBase model No.
Comm. Size
Slots
A3,
A4
Slots
B3,
B4
Slots
A1,
A2
Slots
B1,
B2
Option
Add'l
proc.
Add'l
spec.
Special
support
1 2 3 4 5 6 7 8 9 10 11 12 13
C 7 G Multi-loop controller with multifunction display
A Communication (Ethernet, RS-485, USB)
7 digital input/outputs (sink output, source input)
3 Integrated mounting*
1
4 Standard (separate) mounting
Slot A3 Slot A4
1 PV1 (full-multi) × 1 (No block) AI
2 PV1 (full-multi) + RSP1 (full-multi)*
2
AI AI
Slot B3 Slot B4
0 None (No block) (No block)
1 PV2 (full-multi) × 1 (No block) AI
Selectable if the 6th digit of the model
number (slots A3, A4) = 2 ........................→
2 PV2 (full-multi) + RSP2 (full-multi)*
3
AI AI
Slot A1 Slot A2
C Current output (CT and VT inputs, 1 each) × 1 (No block) AO-C
V Voltage pulse output (2 CT inputs) × 1 (No block) V-P
F Current output (CT and VT inputs, 1 each) × 2 AO-C AO-C
W Voltage pulse output (2 CT inputs) × 2 V-P V-P
N Current output (CT and VT inputs, 1 each) +
voltage pulse output (2 CT inputs)
V-P AO-C
Slot B1 Slot B2
Selectable if the 8th digit of the model number
(slots A1, A2) = C, V, or F ..........................→
0 None (No block) (No block)
Selectable if the 8th digit of the model number
(slots A1, A2) = C, F, or N .........................→
C Current output (CT and VT inputs, 1 each) × 1 (No block) AO-C
Selectable if the 8th digit of the model number
(slots A1, A2) = C, V, W, or N ......................→
V Voltage pulse output (2 CT inputs) × 1 (No block) V-P
Selectable if the 8th digit of the model number
(slots A1, A2) = F .................................→
F Current output (CT and VT inputs, 1 each) × 2 AO-C AO-C
Selectable if the 8th digit of the model number
(slots A1, A2) = W or N ...........................→
W Voltage pulse output (2 CT inputs) × 2 V-P V-P
Selectable if the 8th digit of the model number
(slots A1, A2) = F or N ............................→
N Current output (CT and VT inputs, 1 each) +
voltage pulse output (2 CT inputs)
V-P AO-C
Selectable if the 8th digit of the model number
(slots A1, A2) = C, F, or N .........................→
G Current output (CT and VT inputs, 1 each) +
additional display unit
HMI2 AO-C
Selectable if the 8th digit of the model number
(slots A1, A2) = C, V, W, or N ......................→
H Voltage pulse output (2 CT inputs) + additional
display unit
HMI2 V-P
Selectable if the 8th digit of the model number
(slots A1, A2) = C, F, or N .........................→
L Current output (CT and VT inputs, 1 each) +
clock (with battery)
CLOCK AO-C
Selectable if the 8th digit of the model number
(slots A1, A2) = C, V, W, or N ......................→
P Voltage pulse output (2 CT inputs) + clock
(with battery)
CLOCK V-P
0 None
0 None
D With inspection report
Y With traceability certificate
A AC power plus CE, KC, GB, and UL compliance
B DC power plus CE, KC, GB, and UL compliance
0 No special support
F Overseas models: switchable between Celsius/Fahrenheit
Do not use these models in Japan.
*1. A rear mounting bracket and a dedicated cable for connecting the display unit are included with the product.
*2. RSP1 can be switched for use as PV3.
*3. RSP2 can be switched for use as PV4.
